| उत्पत्ति के प्लेस: | XI'AN शांक्सी |
| ब्रांड नाम: | XZH TEST |
| प्रमाणन: | ISO |
| मॉडल संख्या: | XHGX507 |
XHGX507 underground cable pipe locator is mainly used for cable fault location, cable identification, cable path and depth measurement. It can complete tasks that could only be accomplished by a few sets of instruments in the past.
Features
The large-screen LCD displays the signal strength, and the bar, arrows and voice prompts make it easy for the operator to judge the underground position of the cable and the fault point. One person can do it all.
All-digital design, clear large-screen LCD graphic display and reliable positioning
Portable and lightweight, easy to carry
Built-in rechargeable battery
Built-in ohmmeter to measure cable loop resistance
Can be used to detect insulation faults up to 2MΩ to ground
With backlight function to adapt to night operation
Built-in ohmmeter to measure cable loop resistance
Display cable depth and current
Main components
This cable pipe locator is mainly composed of transmitter and receiver, with accessories of two clamps, one A-frame and necessary connection wires.
